      Welcome to the Capricorn Municipal Development Guidelines

 - Home Page -




This site is intended to provide a location for the display of engineering drawings and specifications which are approved by Local Governments in the Southern and Central Queensland area. The participating local governments in the project are: Banana Shire Council, Central Highlands Regional Council, Gladstone Regional Council, Isaac Regional Council, Livingstone Shire Council, Maranoa Regional Council and Rockhampton Regional Council.



Welcome to Isaac Regional Council



Isaac Regional Council (IRC) has recently joined the group. IRC requirements are now incorporated into the documentation.





Please contact the relevant local government before using any documents labelled draft from this website.

Note that each standard drawing has an 'applicability box' in the bottom right hand corner which specifies to which Council each drawing applies.

It should be noted that the Construction Specifications must be used for municipal works in the Council regions listed below. A check should be made with the Council Specific Info page to ensure that the there are no specific additional requirements of the relevant Local Government.




RECENT CHANGES

JUNE 2017

The following CMDG standard drawings have been amended.

CMDG-I-001-Rev H - Amend W-072 Title.

CMDG-D-010-Rev G - Minor Correction - Alternative B & Table.

CMDG-D-022-Rev F - Note 13 added regarding reinforcement of concrete in-situ pits.

CMDG-D-030-Rev E - Note 6 added regarding reinforcement of concrete in-situ pits.

CMDG-W-071-Rev I - Structural Details Removed.

CMDG-W-072-Rev H - Structural Details Removed.

CMDG-W-073-Rev I - Structural Details Removed.














The site has two main parts:

1. A common set engineering drawings and specifications which are common to all Local Governments
2. Council specific drawings



The Standard Drawings and General Specifications were prepared to assist in the design and construction of municipal road and hydraulic infrastructure.  The documents are designed to be used in conjunction with each other. Council does not consider that the documents are suitable for use for any other purpose.



If you use these documents for any other purpose which is not consistent with the above, you do so at your own risk.



The drawings only provide the minimum Council requirements. It is the responsibility of the user to ensure that the design and construction works satisfy all legislative requirements and all the relevant Australian Standards.



You may print a copy of the specifications and/or drawings for your own use, but they must not be reproduced or modified for any other purpose without prior written approval of the CMDG Technical Reference Group.



For further information contact the technical reference group co-ordinator Chris Hegarty of Cardno (Qld) Pty Ltd Rockhampton Office by email chris.hegarty@cardno.com.au



It is the responsibility of the user to ensure they have the latest version of either the Standard Drawings or General Specifications.  A historical record of amendments can be found on the News & Updates page.
